CP1L

High Performing Programmable Controller with Embedded Ethernet

• “CP1L-EM” and “CP1L-EL” have complete with a Ethernet port.

• Pulse output for two axes. Advanced power for high-precision positioning control.

• High-speed Counters. Single-phase for four axes.

• Six interrupt inputs are built in. Faster processing of instructions speeds up the entire system.

• Serial Communications. Two ports. Select Option Boards for either RS-232C or RS-485 communications.

• “CP1L-M” and “CP1L-L” have a peripheral USB port.

• The Structured Text (ST) Language. Makes math operations even easier.

• Can be used for the CP1W series Unit. The extendibility of it is preeminently good.

• LCD displays and settings. Enabled using Option Board.

CP1L-L10DR-A
CP1L-L10DT-A
CP1L-L10DR-D
CP1L-L10DT-D
CP1L-L10DT1-D
CP1L-L14DR-A
CP1L-L14DT-A
CP1L-L14DR-D
CP1L-L14DT-D
CP1L-L14DT1-D
CP1L-L20DR-A
CP1L-L20DT-A
CP1L-L20DR-D
CP1L-L20DT-D
CP1L-L20DT1-D
CP1L-EL20DR-D
CP1L-EL20DT-D
CP1L-EL20DT1-D
CP1L-M30DR-A
CP1L-M30DT-A
CP1L-M30DR-D
CP1L-M30DT-D
CP1L-M30DT1-D
CP1L-M40DR-A
CP1L-M40DT-A
CP1L-M40DR-D
CP1L-M40DT-D
CP1L-M40DT1-D
CP1L-M60DR-A
CP1L-M60DT-A
CP1L-M60DR-D
CP1L-M60DT-D
CP1L-M60DT1-D
CP1L-EM30DR-D
CP1L-EM30DT-D
CP1L-EM30DT1-D
CP1L-EM40DR-D
CP1L-EM40DT-D
CP1L-EM40DT1-D
